Automatic Aluminum Roller Shutter Door 1.2mm Thickness with Remote Control

Product Details

Certification: CCC, ISO9001, CE

Payment & Shipping Terms

Minimum Order Quantity: 100

Price: 55.6

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          automatic aluminum roller shutter door, 1.2mm thick roller shutter door, remote control roller shutter door


Material:	Aluminum Alloy	Wall Thickness:	1.2mm
Slat Width:	77mm	Slat Thickness:	0.45 Mm
Foam Density:	60 KG/ CBM	Weight Per Sq.m:	4.68 KG/ Sq.m
Max Dimensions:	6000*4500 Mm	Guide Rail Size:	8036mm Or 9036mm
Motor Voltage:	220V/50Hz, 380V/50Hz, 110V/60Hz	Motor Capacity:	400KG,600KG,800KG,1000KG,1300KG,1500KG,2000KG
Tubular Motor Torque:	60N, 80N, 120N, 140N, 230N, 300N	Shaft Diameter:	3 Inches, 5 Inches, 6 Inches, 8 Inches, 10 Inches
Slat Type:	With Polyurethane Foam Filled	Guide Rail Material:	Heavy Duty Extruded Aluminum
Bottom Rail Material:	Extruded Aluminum

Material:	Aluminum Alloy
Wall Thickness:	1.2mm
Slat Width:	77mm
Slat Thickness:	0.45 Mm
Foam Density:	60 KG/ CBM
Weight Per Sq.m:	4.68 KG/ Sq.m
Max Dimensions:	6000*4500 Mm
Guide Rail Size:	8036mm Or 9036mm
Motor Voltage:	220V/50Hz, 380V/50Hz, 110V/60Hz
Motor Capacity:	400KG,600KG,800KG,1000KG,1300KG,1500KG,2000KG
Tubular Motor Torque:	60N, 80N, 120N, 140N, 230N, 300N
Shaft Diameter:	3 Inches, 5 Inches, 6 Inches, 8 Inches, 10 Inches
Slat Type:	With Polyurethane Foam Filled
Guide Rail Material:	Heavy Duty Extruded Aluminum
Bottom Rail Material:	Extruded Aluminum

Description

Automatic Aluminum Roller Shutter Door 1.2mm Thickness with Remote Control

Residential Automatic/Electric Motorized Aluminum Garage Door

Product Specifications

Attribute	Value
Model NO.	SAI 77
Material	Aluminum Alloy
Type	Rolling
Open Style	Rolling
Opening Type	With Remote Control
Special Function	Security
Color	as Request
Position	Industrial
Surface Finishing	Finished
Wall Thickness	1.2mm
Transport Package	Carton or Wooden Box
Specification	80 mm
Trademark	Hoful
Origin	China
HS Code	761010
Production Capacity	5000 Square Meters / Month

Product Overview

Aluminum Insulated Roller Shutter Door - Model HAI 77 is an ideal solution for various applications including:

Commercial shops
Factories
Warehouses
Residential garages
Club bars

Key Features

Safety and security
Theftproof design
Heat insulation
Weather resistant
Rustproof construction
Sound insulation

Technical Specifications

Slat:

Width: 77mm
Thickness: 0.45 mm
Type: Polyurethane foam filled
Foam density: 60 KG/CBM
Weight: 4.68 KG/sq.m
Max dimensions: 6000*4500 mm
Standard Color: white (powder coating), other colors available

Components:

Aluminum bottom rail - extruded aluminum construction
Guide rail - heavy duty extruded aluminum "U" guide rail (80*36mm or 90*36mm) with brush strip for quiet operation
Switch button with stainless steel cover box
Endless chain for manual operation during power outages
Motor options: HOFUL brand side motor (400KG-2000KG) or DOOYA tubular motor (60N-300N)
Shutter box (hood) - galvanized steel or aluminum
Shaft (barrel) - galvanized steel (3-10 inches diameter)
Retractable bearing system
Heavy duty steel end plates
Plastic end clips for lateral protection
