HA80 Aluminum Roller Shutter Door 80mm with Remote Control

Product Details

Certification: CCC, ISO9001, CE

Payment & Shipping Terms

Minimum Order Quantity: 50

Price: 52.5

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          aluminum roller shutter door 80mm, remote control roller shutter door, HA80 aluminum shutter with warranty


Model NO.:	HA80	Open Style:	Rolling
Opening Type:	With Remote Control	Slat Width:	80mm
Slat Thickness:	1.0mm, 1.2mm	Guide Rail Size:	8036mm Or 9036mm
Motor Load Capacity:	400KG,600KG,800KG,1000KG,1300KG,1500KG,2000KG	Motor Voltage:	220V/50Hz, 380V/50Hz, 110V/60Hz
Tubular Motor Torque:	60N, 80N, 120N, 140N, 230N, 300N	Shaft Diameter:	3 Inches, 5 Inches, 6 Inches, 8 Inches, 10 Inches
Surface Finishing:	Finished	Standard Color:	White, Beige
Bottom Rail Material:	Extruded Aluminum	Guide Rail Material:	Heavy Duty Extruded Aluminum
Shutter Box Material:	Galvanized Steel Or Aluminum

Model NO.:	HA80
Open Style:	Rolling
Opening Type:	With Remote Control
Slat Width:	80mm
Slat Thickness:	1.0mm, 1.2mm
Guide Rail Size:	8036mm Or 9036mm
Motor Load Capacity:	400KG,600KG,800KG,1000KG,1300KG,1500KG,2000KG
Motor Voltage:	220V/50Hz, 380V/50Hz, 110V/60Hz
Tubular Motor Torque:	60N, 80N, 120N, 140N, 230N, 300N
Shaft Diameter:	3 Inches, 5 Inches, 6 Inches, 8 Inches, 10 Inches
Surface Finishing:	Finished
Standard Color:	White, Beige
Bottom Rail Material:	Extruded Aluminum
Guide Rail Material:	Heavy Duty Extruded Aluminum
Shutter Box Material:	Galvanized Steel Or Aluminum

Description

HA80 Aluminum Roller Shutter Door 80mm with Remote Control

Aluminum Roll up Door / Industrial Aluminum Roll-up Shutter

Product Specifications

Attribute	Value
Model NO.	HA80
Open Style	Rolling
Opening Type	With Remote Control
Special Function	Security
Color	Any RAL Color
Position	Industrial
Surface Finishing	Finished
Transport Package	As Request
Specification	80mm
Trademark	HOFUL
Origin	Made in China
HS Code	761010
Production Capacity	5000 Square Meters/Month

Product Description

The HA80 Aluminum Roller Shutter Door provides an ideal security solution for various applications including commercial shops, factories, warehouses, residential garages, and club bars.

Key Features

Enhanced safety and security
Theftproof design
Excellent heat insulation
Weather resistant construction
Rustproof materials
Effective sound insulation

Technical Specifications

Double Skinned Aluminum Slat (HA80): Width: 80mm | Thickness: 1.0mm, 1.2mm | Standard Colors: White, Beige (Other RAL colors available)

Aluminum Bottom Rail: Made of extruded aluminum

Aluminum Guide Rail: Heavy duty extruded aluminum "U" guide rail (80*36mm or 90*36mm) with brush strip for quiet operation

Switch Button: Stainless steel cover box

Endless Chain: Manual operation option when power is off

Motor Options: HOFUL brand side motor (400KG-2000KG) or DOOYA tubular motor (60N-300N) with various voltage/frequency options

Shutter Box: Optional galvanized steel or aluminum construction

Shaft: Galvanized steel (3-10 inches depending on door size)

Bearing: Retractable, welded according to shutter width

End Plate: Heavy duty steel construction

End Clip: Plastic protection against lateral movement

Manual operation aluminum roller shutter is available upon request.
