Industrial Aluminum Roller Shutter Door 80mm with Remote Control

Product Details

Certification: CCC, ISO9001, CE

Payment & Shipping Terms

Minimum Order Quantity: 100

Price: 52.5

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          industrial aluminum roller shutter door, 80mm roller shutter door with remote, remote control aluminum shutter door


Model NO.:	HA80+HA80-2	Open Style:	Rolling
Opening Type:	With Remote Control	Wall Thickness:	1.2mm
Specification:	80 Mm	Slat Width:	80mm
Slat Thickness:	1.0mm, 1.2mm	Guide Rail Size:	8036mm Or 9036mm
Motor Load Capacity:	400KG,600KG,800KG,1000KG,1300KG,1500KG,2000KG	Motor Voltage:	220V/50Hz, 380V/50Hz, 110V/60Hz
Tubular Motor Torque:	60N, 80N, 120N, 140N, 230N, 300N	Tubular Motor Voltage:	230V/50Hz, 120V/60Hz
Shaft Diameter:	3 Inches, 5 Inches, 6 Inches, 8 Inches, 10 Inches	Guide Rail Material:	Heavy Duty Extruded Aluminum
Bottom Rail Material:	Extruded Aluminum

Model NO.:	HA80+HA80-2
Open Style:	Rolling
Opening Type:	With Remote Control
Wall Thickness:	1.2mm
Specification:	80 Mm
Slat Width:	80mm
Slat Thickness:	1.0mm, 1.2mm
Guide Rail Size:	8036mm Or 9036mm
Motor Load Capacity:	400KG,600KG,800KG,1000KG,1300KG,1500KG,2000KG
Motor Voltage:	220V/50Hz, 380V/50Hz, 110V/60Hz
Tubular Motor Torque:	60N, 80N, 120N, 140N, 230N, 300N
Tubular Motor Voltage:	230V/50Hz, 120V/60Hz
Shaft Diameter:	3 Inches, 5 Inches, 6 Inches, 8 Inches, 10 Inches
Guide Rail Material:	Heavy Duty Extruded Aluminum
Bottom Rail Material:	Extruded Aluminum

Description

Industrial Aluminum Roller Shutter Door 80mm with Remote Control

Residential/Industrial Motorized & Manual Operated Aluminum Roller Shutter Door

Product Specifications

Attribute	Value
Model NO.	HA80+HA80-2
Open Style	Rolling
Opening Type	With Remote Control
Special Function	Security
Color	as Request
Position	Industrial
Surface Finishing	Finished
Wall Thickness	1.2mm
Transport Package	Carton or Wooden Box
Specification	80 mm
Trademark	Hoful
Origin	China
HS Code	761010
Production Capacity	5000 Square Meters / Month

Product Overview

Ideal solution for:

Commercial shops Factories Warehouses Residential garages Club bars

Key Features

Safety and security protection
Theftproof design
Effective heat insulation
Weather resistant construction
Rustproof materials
Sound insulation properties

Technical Specifications

Double layer aluminum Slat (HA80) + single layer aluminum Slat (HA80-2): Width: 80mm, Thickness: 1.0mm/1.2mm, Standard colors: white, beige (custom RAL colors available)
Aluminum bottom rail: Made of extruded aluminum
Aluminum Guide Rail: Heavy duty extruded aluminum "U" guide rail (80*36mm or 90*36mm) with brush strip for quiet operation
Switch button: Stainless steel cover box
Endless chain: Manual operation option during power outage
Motor options: HOFUL brand side motor (400KG-2000KG) or DOOYA tubular motor (60N-300N) with various voltage/frequency options
Shutter box (hood): Galvanized steel or aluminum option
Shaft (barrel): Galvanized steel, sizes from 3-10 inches
Bearing: Retractable, welded according to shutter width
End plate: Heavy duty steel, fixed on shaft sides
End clip: Plastic protection against lateral movement
