HA80 Aluminum Roller Shutter Door 7500x7500mm with Remote Control

Aluminum Alloy white color wood grain color Garage Door Roll up Roller Shutter Door

Ideal solution for various applications:

• Safety and security
• Theftproof design
• Heat insulation
• Weather resistant
• Rustproof construction
• Sound insulation

1. Double Skinned Aluminum Slat (HA80)
   Width: 80mm
   Thickness: 1.0mm, 1.2mm
   Standard Colors: white, beige, other RAL colors available
2. Aluminum Bottom Rail
   Made of extruded aluminum
3. Aluminum Guide Rail
   Heavy duty extruded aluminum "U" guide rail (80*36mm or 90*36mm)
   Includes brush strip for quiet operation
4. Switch Button
   Stainless steel cover box
5. Endless Chain
   Manual operation option when power is off
6. Rolling Shutter Motor Options
   Option 1: HOFUL brand side motor (CE certified)
   Capacities: 400KG-2000KG
   Voltage/Frequency: 220V/50Hz, 380V/50Hz, 110V/60Hz

   Option 2: DOOYA tubular motor (CE certified)
   Torque options: 60N-300N
   Voltage/Frequency: 230V/50Hz, 120V/60Hz
7. Shutter Box (Hood)
   Material options: galvanized steel or aluminum
8. Shaft (Barrel)
   Galvanized steel, sizes: 3", 5", 6", 8", 10" (size dependent on shutter dimensions)
9. Bearing
   Retractable design, welded according to shutter width
10. End Plate
    Heavy duty steel, fixed on both sides of shaft
11. End Clip
    Plastic construction, prevents lateral movement of curtain

Manual operation aluminum roller shutter is available upon request.
