HA80 Wood Grain Aluminum Roller Shutter Door 80mm Width

Product Details

Certification: CCC, ISO9001, CE

Payment & Shipping Terms

Minimum Order Quantity: 100

Price: 54.5

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          wood grain aluminum roller shutter door, 80mm width roller shutter door, aluminum roller shutter door with warranty


Slat Width:	80mm	Slat Thickness:	1.0mm, 1.2mm
Slat Color:	Wood Grain, Wood Color	Guide Rail Dimensions:	8036mm Or 9036mm
Motor Load Capacity:	400KG,600KG,800KG,1000KG,1300KG,1500KG,2000KG	Motor Voltage/Frequency:	220V/50Hz, 380V/50Hz, 110V/60Hz
Tubular Motor Torque:	60N, 80N, 120N, 140N, 230N, 300N	Tubular Motor Voltage:	230V/50Hz, 120V/60Hz
Shaft Diameter:	3 Inches, 5 Inches, 6 Inches, 8 Inches, 10 Inches	Guide Rail Material:	Heavy Duty Extruded Aluminum
Bottom Rail Material:	Extruded Aluminum	Shutter Box Material:	Galvanized Steel Or Aluminum
End Plate Material:	Heavy Duty Steel	End Clip Material:	Plastic
Production Capacity:	3000 Square Meters/ Month

Slat Width:	80mm
Slat Thickness:	1.0mm, 1.2mm
Slat Color:	Wood Grain, Wood Color
Guide Rail Dimensions:	8036mm Or 9036mm
Motor Load Capacity:	400KG,600KG,800KG,1000KG,1300KG,1500KG,2000KG
Motor Voltage/Frequency:	220V/50Hz, 380V/50Hz, 110V/60Hz
Tubular Motor Torque:	60N, 80N, 120N, 140N, 230N, 300N
Tubular Motor Voltage:	230V/50Hz, 120V/60Hz
Shaft Diameter:	3 Inches, 5 Inches, 6 Inches, 8 Inches, 10 Inches
Guide Rail Material:	Heavy Duty Extruded Aluminum
Bottom Rail Material:	Extruded Aluminum
Shutter Box Material:	Galvanized Steel Or Aluminum
End Plate Material:	Heavy Duty Steel
End Clip Material:	Plastic
Production Capacity:	3000 Square Meters/ Month

Description

HA80 Wood Grain Aluminum Roller Shutter Door 80mm Width

European-Style Wood Colour Aluminum Garage Doors

Product Specifications

Attribute	Value
Model NO.	HA80
Open Style	Rolling
Opening Type	With Remote Control
Special Function	Security
Color	Wood Grain
Position	Industrial
Surface Finishing	Finished
Transport Package	Carton or Wooden Box
Specification	CE
Trademark	Hoful
Origin	China
HS Code	761010
Production Capacity	3000 Square Meters/Month

Product Description

Aluminum Roller Shutter Door - Model HA80 is an ideal solution for various applications including:

Commercial shops
Factories
Warehouses
Residential garages
Club bars

Key Features

Safety and security
Theftproof design
Heat insulation
Weather resistant
Rustproof construction
Sound insulation

Technical Specifications

1. Double Skinned Aluminum Slat (HA80):
Width: 80mm
Thickness: 1.0mm, 1.2mm
Color: wood grain, wood color

2. Aluminum Bottom Rail:
Made of extruded aluminum

3. Aluminum Guide Rail:
Made of heavy duty extruded aluminum "U" guide rail, 80*36mm or 90*36mm (Width*Depth*thickness)
Includes brush strip for quiet operation

4. Switch Button:
Stainless steel cover box for operating rolling shutter

5. Endless Chain:
Allows manual operation during power outages

6. Rolling Shutter Motor Options:
Option 1: HOFUL brand side motor (CE certified) with various capacities from 400KG to 2000KG
Voltage/Frequency options: 220V/50Hz, 380V/50Hz, 110V/60Hz

Option 2: DOOYA tubular motor (CE certified) with torque options from 60N to 300N
Voltage/Frequency options: 230V/50Hz, 120V/60Hz

7. Shutter Box (Hood):
Optional galvanized steel or aluminum construction

8. Shaft (Barrel):
Galvanized steel, available in 3", 5", 6", 8", or 10" diameters depending on shutter size

9. Bearing:
Retractable design, welded according to shutter width

10. End Plate:
Heavy duty steel construction, fixed on both sides of shaft

11. End Clip:
Plastic construction to prevent lateral movement of curtain

Manual operation aluminum roller shutter is available upon request.
